2.6. Details of Wrist Axis Attachment Surface

2.6. Details of Wrist Axis Attachment Surface​



When attaching the operating tool to the mechanical interface of robot's wrist flange, fasten it with a bolt at P.C.D. 100.





Figure 2.9 Details of Wrist Axis Attachment Surface : [YS080/YS100A/HH050/HH030L/HH050T]
