5.1.7. Gas Spring Bearing

Figure 5.7 Gas Spring Grease Inlet/Outlet

n Grease injection method

(1) Open a nipple cap 1/8, and inject grease using a grease gun through the grease nipple A-PT1/8.

ü Grease type : GADUS S2 V46 2

ü Initial amount of grease injection: 15cc (13.5g)

ü Amount of grease refueling: 7cc (6.3g)

(2) Clean up discharged grease caused by excessive fueling with a cloth.

(3) Clean the inlet, and assemble the nipple cap as it was.
