2.7. Details of Upper 1st ARM Attachment Surface

The upper parts of the arm frame and arm pipe of the robots are attached using a tap designed to attach peripheral devices. Within the area marked with ▦, peripheral devices (valves, etc.) shall be attached.

[Attention]

n Max weight on the A1 Frame : 20kg
