5.1.1. S-Axis Reduction Gear

5.1.1. S-Axis Reduction Gear





Attention   If the grease is injected without removing the plug of the outlet, the grease may cause damage to the motor by flowing into it. Be sure to remove plug.



n  Grease Replacement



(1)   Remove the grease outlet plug.



(2)   Inject the grease into the grease inlet using a grease gun



ü  Grease type : VIGO GREASE RE0 ü  Amount of grease: 4,222cc / 3.8 Kg



(3)    The grease replacement is complete when new grease appears in the outlet port. The new grease can be distinguished from the old one by color..



(4)   Discharge excessively fueled grease and residual pressure. (Refer to the discharge procedure below.)



(5)   Clean the greased around the outlet and assemble the seal-taped plug into its original state..



n  Procedure in discharging excessively fueled grease and residual pressure after grease replacement and injection



(1)   Attach a grease receiver or a hose to the grease outlet to prevent contamination from discharged grease.



(2)   Operate it within a range without surrounding and interference under the following conditions.

①    Operation angle : 80° or more

②    Operation speed : 100%

③    Operation time: 20 minutes or more



(3)    Wipe the outlet port with a cloth and attach the plug.



Attention   If the existing injection grease specification is MOLYWHITE RE00, VIGO GREASE RE0 must be injected after over 100 hours.
