4.3. Inspection of Main External Bolts

4.3. Inspection of Main External Bolts​



 The recommended bolt torque is shown in [Figure 4.1]

Apply the appropriate torque, where required, using the torque wrench and place the paint marking where the check-up is completed. Use 12.9T(strength grade) for bolts.





Table 4‑3 Inspection part for main bolts

No.

Inspection parts

No.

Inspection parts

1

S axis motor assembly bolt

8

R2 axis MOTOR BASE

2

S axis MOTOR BASE

9

B axis motor assembly bolt

3

H axis motor assembly bolt

10

B axis MOTOR BASE

4

V axis motor assembly bolt

11

R1 axis motor assembly bolt

5

V axis MOTOR BASE

12

R1 axis MOTOR BASE

6

V axis MOTOR BASE

13

END EFFECTOR assembly bolt

7

R2 axis motor assembly bolt









Figure 4.1Inspection part for main bolts
