4.3. Inspection of Main External Bolts
4.3. Inspection of Main External Bolts
The recommended bolt torque is shown in [Figure 4.1].
Apply the appropriate torque, where required, using the torque wrench and place the paint marking where the check-up is completed.
Table 4‑3 Inspection part for main bolts
No. | Inspection parts | No. | Inspection parts |
1 | H-axis reducer seal bolt | 6 | ARM PIPE seal bolt |
2 | H-axis motor seal bolt | 7 | R2-axis reducer seal bolt |
3 | V-axis reducer seal bolt | 8 | Wrist assembly seal bolt |
4 | V-axis motor seal bolt | 9 | B-axis reducer seal bolt |
5 | Wrist axis(R2, B and R1) motor seal bolt | 10 | R1-axis reducer seal bolt |
Figure 4.1 Inspection Part for Main Bolts [YS080L/YS140]
