2.8. Wiring and Piping Drawings for Application

There are air unit and connector to connect the additional equipment to the robot manipulator.

Application connectors are indicated as follows.

[Note] Max air pressure of air connection: 5bar (5.1 kgf/cm2, 72.5 psi)
