4.3. Inspection of Main External Bolts
4.3. Inspection of Main External Bolts
The recommended bolt torque is shown in [Figure 4.1] ~ [Figure 4.2].
Apply the appropriate torque, where required, using the torque wrench and place the paint marking where the check-up is completed.
Table 4‑3 Inspection part for main bolts
NO. | Inspection parts |
1 | For fixing the motor base of axes H and V’s reducer |
2 | H, V axis motor fixation |
3 | Balance Spring fixation |
4 | Link fixation |
5 | R-link seal |
6 | C-link seal |
7 | T-link seal |
8 | R2 axis motor fixation |
9 | End effect fixation |
Figure 4.1 Inspection Part for Main Bolts
