2.7. Wiring and Piping Drawings for Application

2.7. Wiring and Piping Drawings for Application​



There are air unit and connector to connect the additional equipment to the robot manipulator.

Application connectors are indicated as follows.





Figure 2.6 Wiring and piping drawings for application: [HH007C]
