2.4. Robot Dimension and Working Envelope

2.4. Robot Dimension and Working Envelope​





Figure 2.3 Robot Dimension and Working Envelope : [HA006]





Figure 2.4 External dimension and operating area of main body: [HA020]





Figure 2.5 External dimension and operating area of main body: [HA010L]
