2.6. Details of Wrist Axis Attachment Surface

2.6. Details of Wrist Axis Attachment Surface



When attaching the work tool on the flange of the wrist end, use the bolt of the applicable model.





Figure 2.5 Details of Wrist Axis Attachment Surface
